What are the range parameters of the crystal peak vortex flowmeter? Currently, the specific range parameters of the crystal peak vortex flowmeter are not clearly provided in public information.
1. General Definition of Range for Vortex Flow Meter The range of a vortex flow meter generally refers to the range from the minimum flow rate (lower limit) to the maximum flow rate (upper limit) that can be accurately measured, with commonly used flow units such as m ³/h, kg/h, or flow velocity m/s.
; The range ratio is the ratio of the maximum and minimum measurable flow rates to the rock fracture value. The mainstream product range ratios are mostly 1:10, 1:1
5, 1:20. The higher the ratio, the better the stability of accuracy in a wide flow range.
2. Reference Examples for Range of Similar Vortex Flowmeters: There are significant differences in the range of vortex flowmeters of different specifications and models. The publicly available reference parameters for similar products are as follows:
1. WT200 caliber 15mm: minimum flow rate of 100L/h, maximum flow rate of 600m ³/h. 2. WT300 caliber 20mm: minimum flow rate of 200L/h, maximum flow rate of 1200m ³/h.
3. Ways to obtain accurate range closure of crystal peak vortex flowmeters. If you need to obtain specific range parameters of crystal peak brand vortex flowmeters, it is recommended to consult the manufacturer or distributor of the brand directly.
; When selecting, it is necessary to provide parameters such as measuring medium, pipe diameter, temperature, pressure, etc., in order to obtain a precise range solution that is suitable.2. Briefly describe the working principle and characteristics of vortex flowmeter.
>
[Answer]: Vortex flowmeter, also known as vortex flowmeter or Karman vortex flowmeter. It is a vortex separation flowmeter made using the principle of natural fluid oscillation. When a fluid flows through an object perpendicular to its flow direction at a sufficiently high velocity, if the geometric dimensions of the object are appropriate, a neat arrangement of vortices will be generated behind the object along two parallel straight lines, turning in opposite directions. The number of vortices, i.e. vortex street frequency, is directly proportional to the velocity of the fluid. Therefore, by measuring the vortex frequency, the flow velocity of the fluid can be determined, thereby measuring the fluid flow rate. The Doppler point of the vortex flowmeter has high accuracy, wide measurement range, no moving parts, no mechanical wear, easy maintenance, low pressure loss, and significant energy-saving effect.
3. What are the advantages of vortex flowmeter
Function
1. The body also integrates temperature and pressure compensation function, which can measure the standard volume flow rate or standard mass flow rate of the fluid.
.2、 Fully intelligent and digital circuit design, capable of automatically compensating for measured fluid density or standard condition volume calculation.
3、 The new digital filtering and correction functions make flow measurement more accurate and reliable.
4、 The battery powered type can work continuously for more than two years without the need for an external power source.
5、 The brand new dot matrix Chinese character LCD display is more convenient to use and operate. /iknow-pic.cdn.bcebos.com/cf1b9d16fdfaaf5171634bd2835494eef11f7adf"target="
